作用与概况/Brief Introduction：

该主产品组为10-20ml服用液固态罐装生產线中的大部分主产品。是由洗瓶、干燥分立式机和罐装封膜分立式机所形成，能自己搞定服用液瓶的洗瓶、干燥、罐装和封膜等瑜伽动作，是服用液生產厂商更理想型的服务设施主产品，完完全全适用GMP让。It’s a major equipment in production line for oral filling, it main used in filling, capping placing and sealing of 10-20ml bottles. Tracking filling, cap automatically conveying by electromagnetic oscillator, automatic sealing , no bottle no filling. Filling and sealing integrated in one machine, advanced design, compact structure and completely comply with requirement of GMP

显著特点/Characteristic：

◆装量精确，坚决杜绝漏滴。装罐精确高。High filling accuracy.◆变频式魔宗变频调速，研发加线速度可变，可选择择有差异的研发加线速度。Frequency control, production speed is adjustable, you can choose a different production rate.◆其他家电pcb板均用于进口货出名店牌。All electrical components are imported famous brands.◆定时表明计数器性能。Automatically countting function.◆保持选取德国三凌PLC，抗不干扰，本职工作稳定性高。Controlled by Mitsubishi PLC◆功效维持，保护养生保健不方便。Stable performance, easy maintenance.◆空机外表层选取SUS304不锈碳钢作、与原辅料接受那部分选取316L304不锈钢材质的。空机可以按GMP让设计的。Outer material is 304 stainless steel, and the material of filling part is 316L stainless steel. The machine is completely designed according to GMP requirements.

技术工艺技术指标/technical parameters：

适用于样式/Bottle size	10-20ml
的生扩产力/Capacity	60-90瓶/小时/60-90bottles/min
烘干箱温/Dryer tempreture	100-300°
回收利用水排水量量/Water wastage	0.5m3/h
净化处理水耗量/Purifying water consumption	0.3m3/h
装量表面粗糙度/Filling precision	≤1%
电源线/Voltage	380V/50Hz
效率/Power	33KW
加工线总长/Dimension	3500×1500×1600mm
